PERFORMANCE
FRAME - 6061 Double-Butted Aluminum Alloy with Internal Battery
MOTOR - 1250W (Peak) 1000W (Sustained), 48V Brushless Rear Hub BAFANG Motor
SPEED - Up to 28 MPH on Pedal Assist and 28 MPH on Throttle
RANGE - 45-55 Miles per charge (estimate)
BATTERY - Removable Internal Lithium-ion 48V ,17.5AH (840WH) SAMSUNG
DISPLAY - CloudDrive CDC6-PR02 Backlit LCD Display
WEIGHT LIMIT - Maximum Payload Capacity: 275 LBS
WEIGHT - 90 LBS
ELECTRIC SYSTEM
CHARGER - 48V 3 Amp Smart Charger, 4-6 Hour Charge Time
CONTROLLER - 48V, 1000W Frame-integrated Controller
THROTTLE - Thumb Throttle
PEDAL ASSIST - Intelligent 5 level pedal assist with 24 magnet cadence sensor
Wiring - Water resistant connectors and wiring harness
HEADLIGHT - High output LED Headlight with turning light
TAILLIGHT - Red LED with turning light and brake light
COMPONENTS
FORK - Hydraulic Fork, 100mm Travel, with lockout and preload adjustment
BRAKE - Tektro 180mm Front & 180mm Rear Hydraulic Disc Brake
SHIFT LEVER - Shimano 7 Speed Shifter
CRANKSET - Prowheeel 46T 170mm Crankset
CASSETTE - Shimano 14T-28T Cassette
CHAIN - KMC Rust Resistrant Chain
HANDLEBARS - Aluminum 22.2mm, 750mm Back Sweep 8.5 Degree
GRIPS - Durable Ergonomic Grips
STEM - Aluminum Alloy, 48mm Length, 22.2mm
REAR RACK - 55lbs Rated Loading Weight
RIM - Double Wall Aluminum 36h Front & Rear
TIRES - KENDA 20X4 .0 Front & Rear Tires
FENDERS - Full coverage front and rear
SADDLE - Kasen
PEDALS - Wellgo Aluminum Alloy pedals
